Description
Technical Specifications
| Screen | 10.1 in (3.93 cm) TFT LCD |
| Resolution | 800 pixels × 1280 pixels PPI |
| Aspect Ratio | 16:10 |
| Brightness | 1000 NITS |
| CPU | Qualcomm Cortex-A 53 4bit Octa-core processor 1.8 GHz |
| GPU | Adreno 506 |
| Ram + Rom | 2 GB LPDDR 3+ 16 GB EMMC, 4 GB LPDDR 3+ 64 GB EMMC (optional) |
| Lan | 100 M × 1 (POE for optional) |
| Com | RS 232 × 3 |
| Sim Card Slot ×1 | 1.8 V or 2.95 V |
| TF Card Slot ×1 | 1.8V or 2.95 v, up to 128 GB |
| USB | USB OTG × 1 USB Host × 1 Up to 480 Mbps |
| DC In | × 1 |
| Earphone Jack | × 1 |
| Cellular Network | 3 G or 4 G |
| Wi-Fi | IEEE 802.11 a or b or g or n or a |
| BT | Built-in Bluetooth 4.2 LE + EDR 2 |
| GNSS | GPS and GLONASS (optional） |
| Camera | 5.0 MP (Front camera for optional) |
| Power Supply | DC 9 V to 36 V (DC 11 V to 36 V with built-in battery) |
| Power Consumption | ≤ 10 W (≤ 18 W with built-in battery) |
| Battery (Optional) | Built-in 3.7 V 3500 mAh |
| Speaker | Built-in 2 W, 85 dB |
| Power Consumption | ≤ 8 W |
| Environment | Operating temperature: 14 °F to 140 °F (-10 °C to 60 °C)
Storage temperature: -4 °F to 149 °F (-20 °C to + 65 °C) |
| Dimension | 9.80 in x 6.53 in x 1.25 in (249 mm x 166 mm x 32 mm) |
| Weight | 2.16 lb (980 g) |
