| Material |
ABS |
| Antenna |
3 dBi circularly polarized antenna (Built in) |
| Input Voltage |
DC 12 V to 24 V/3 A |
| Peak Current |
60 mA (DC 12 V) |
| RFID Parameters (Air Protocol) |
EPC global Gen2 (ISO18000-6C) |
| Working Frequency |
865 MHz to 868 MHz or 920 MHz to 925 MHz or 902 MHz to 928 MHz (custom-design for frequency band) |
| Read Mode |
Read once, continuous reading; KB port output |
| Reading Distance |
Up to 31.4 in (80 cm) (relate to tag and environment) |
| Interfaces |
1, Plug & Play Keyboard Emulation (KB) Port 2, USB to Serial Port (COM) Port |
| Datasheet |
SDK (download link) C#, Java, C++ |
| Operating Temperature |
-40 °F to 167 °F (-40 ℃ to +75 ℃) |
| Storage Temperature |
-40 °F to 185 °F (-40 ℃ to +85 ℃) |
| Humidity |
5 % to 90 % non-condensing 167 °F (+75 ℃) |
| Dimensions |
5.5 in x 3.3 in x 0.7 in x (142 mm x 85 mm x 20 mm) |
| Net Weight |
4.6 oz (132 g) |
