Description
Overview
Cutting-edge RFID reader with broad compatibility: EPC C1 GEN 2 & ISO18000 6C protocol, versatile communication options, and extensive read distance.
Technical Specifications
| Frequency | 840 MHz to 960 MHz |
| Protocol | EPC C1 GEN 2 & ISO18000 6C |
| Communication | Standard:RS232, Ethernet (RJ45), USB Optional: WIFI, RS485 |
| Power Supply | DC 12 V |
| Ic Type | M7131 |
| Read Distance | ≥ 49.2 ft (15 m) (with 12 dBi antenna) |
| Working Mode | Passive |
| Multi-Tags Reading | ≥ 400 tags per s |
| Ip Rating | IP64 |
| Support Area | China, Europe, North America, South Korea, Japan, Taiwan… |
| Output Power | Software adjustable, step interval 1.0 dB, maximum +30 dBm |
| Output Power Flatness | ±0.2 dBm |
| Receiving Sensitivity | -82 dBm |
| Radio Frequency Port Standing Wave | ≤ 1.5 |
| Interface Communication Rate | 115200 bps |
| Antennae Interface | Four (TNC) |
| Material | Aluminum Alloy Enclosure |
| Working Humidity | 5 % to 95 % RH |
| Working Temperature | -22 °F to 158 °F (-30 °C to + 70 °C) |
| Storage Temperature | -40 °F to 185 °F (-40 °C to + 85 °C) |
| Size | 10.43 in x 7.56 in x 1.69 in (265 mm x 192 mm x 43 mm) |
