Description
Features
• Professional measurement, curve, list, map are displayed simultaneously
• Auto OTDR, no complex settings, one key test
• Supports CW, 270,330, 1 k, 2 kHz frequency identification
• VFL and LS can run in the background
• Multitask can be operated simultaneously
• LS supports CW modulation mode output with adjustable output power
• RJ45 cable tracker of digital radar, stronger anti jamming ability
• RJ45 cable sequence, cable length test, up to 300 m
• One click screen capture, easy to save the interface
• Support ILOM, support SC, APC
Technical specifications
| Wavelength | 1310 nm, 1550 nm, 1625 nm |
| Event Blind Zone | 2.5 m (8.20 ft) |
| ATT Blind Zone | 8 m (26.24 ft) |
| Interface | UPC, APC optional |
| Screen | 4.3 inch touch screen |
| Battery | 4000 mAh, 3.7 V |
| Adapter | ST, SC, FC optional |
| Data Interface | USB |
| Battery Working | More than 12 hours |
| Test Range | 500 m (1640.41 ft), 1 km (3280.83 ft), 2 km (6561.67 ft), 4 km (13123.35 ft), 8 km (26246.71 ft), 16 km (52493.43 ft), 32 km (104986.87 ft), 64 km (209973.75 ft), 100 km (328083.99 ft) |
| Pulse Width | 3 ns, 5 ns, 10 ns, 20 ns, 30 ns, 50 ns, 80 ns, 160 ns, 320 ns, 500 ns, 800 ns, 1 us, 2 us, 3 us, 5 us, 8 us, 10, us, 20 us |
| Ranging Accuracy | ± (1 m (3.28 ft) + sample interval + 0.005% x test distance) |
| Linearity | ≤ 0.05 dB per dB |
| Sample Points | 16 k to 128 k |
| Sample Resolution | 0.05 m to 8 m (0.16 ft to 26.24 ft) |
| Loss Resolution | 0.001 dB |
| Loss Threshold | 0.20 dB |
| Range Resolution | 0.001 m (0.0032 ft) |
| Refractive Index | 1.00000 to 2.00000 |
| Reflection Accuracy | ± 3 dB |
| File Format | SOR standard file format |
| Loss Analysis | 4 point method, 5 point method |
| Laser Safety Level | Class II |
| Connector | FC UPC (Interchangeable SC, ST) or SC APC |
| Refresh Rate | 3 Hz (Typ.) |
| Package Size | 8.66 in x 4.72 in x 3.54 in (22 cm x 12 cm x 9 cm) |
| Gross Weight | 2204.62 lbs (1000 kg) |
