| Power Supply |
Built-in and External are available |
| Output Power |
15.4 W / 30 W |
| POE Port |
1 to 4 support IEEE802.3AF/AT |
| Power Pin |
Both (1/2)+, (3/6)- and (4 / 5)+ (7 / 8)- |
| POE Type |
End-span |
| Whole Power |
≤72 W (52 V 1.4 A) |
| Network Medium |
10 / 100 BASE-TX: 5 class and above non shielded twisted pair |
| Power Distance |
≤ 9842.5 in (250 m) |
| Switch Capability |
1.2 Gbps |
| Data Distance |
≤ 9842.5 in (250 m) |
| Forwarding Mode |
Store and forward |
| Forwarding Rate |
10 BASE-T:14880PPS / port, 100BASE-tx: 14800 pps / port |
| MAC Address |
MAC address table 1K |
| Port Function |
Power priority mechanism, fast and forward, MAC automatic learning and aging, IEEE802.3X Full-duplex and mode and backpressure for Half-duplex mode |
| LED Indicator |
LINK / ACT.100 Mbps, POE Status Indicator, Power indicator, Extender |
| Size |
7.95 in x 5.51 in x 1.77 in (202 mm x 140 mm x 45 mm) |
