| Serial TV BNC Input or Output |
| Input Channel |
16 |
| Output Channel |
16 |
| TV Signal Standard |
SMPTE 292M, 259M, 297M, 305M, 310M, M2S, DVB-ASI, DVB-SSI and other Telecom or Datacom rate (19.4 Mb/s to 1.485 Gb/s) |
| Reflection Loss |
>15 dB |
| Equilibrium |
0 mi to 0.09 mi (0 m to 150 m) 1.485 Gb/s |
| Connector |
75 Ω BNC |
| Signal Level |
800 mV nominal |
| Rise or Fall Time |
200 Ps nominal |
| Overshoot |
<10% amplitude |
| Reflection Loss |
>15 dB |
| Jitter |
<0.2 UI |
| Connector |
75 Ω BNC |
| Audio |
| Channel |
1 (unidirectional or bi-directional) |
| Connector |
Terminal Block with Screw Clamps |
| Data |
| Channel |
1 |
| Data Format |
RS232, RS-485, RS422 (full or half duplex) and support NRZ, RZI and Manchester |
| Optic |
| Channel |
1 |
| Type |
Single-mode or fiber (multimode optional) |
| Wavelength |
1310 nm or 1550 nm |
| Reflection Loss |
>15 dB |
| Connector |
FC or PC (ST or PC optional) |
| Power And Environmental Indicator |
| EMI Or RFI |
FCC Part 15 Class A, EU EMC standard |
| Average Time Trouble-free |
>100000 hrs |
| Operating Temperature |
-40 ℉ to 122 ℉ (-40 ℃ to 50 ℃) |
| Dimension |
8.97 in x 7.08 in x 1.18 in (228 mm x 180 mm x 30 mm) |
| Weight |
4.40 lb (2 kg) |
