| Operating Frequency |
EU 865 MHz to 868 MHz or US 902 MHz to 928 MHz |
| Chip |
Chinese R2000-LTE |
| Read Range |
3.2 ft to 98.4 ft (1 m to 30 m) (depends on tag and antenna) |
| Read Tag |
Multiple tags, 1 to 400 tags per s (depends on antenna per tag) |
| Interface (Connector) |
USB, Ethernet (10/100 Base-T RJ45), RS-232, RS-485 (Opt.) |
| Protocol |
EPC global UHF Class 1 Gen 2 ISO 18000-6C and ISO 18000-6B |
| Antenna Connector |
SMA |
| Output Power |
18 dBm to 33 dBm |
| Tag Cache |
1000 tags at 96-bit EPC |
| Shell Material |
Cast aluminum |
| Channel Isolation |
> 30 dB |
| Output Power Precision |
+/- 1 dB |
| Output Power Flatness |
+/- 0.2 dB |
| Receive Sensitivity |
< -85 dBm |
| Tag RSSI |
Supported |
| Antenna Detector |
Supported |
| Ambient Temp Monitor |
Supported |
| Working Mode |
Single/DRM |
| GPIO |
2 inputs, 2 outputs (optically isolated) |
| Power Supply |
+12V DC at 2A |
| Power Consumption |
< 7W at 30 dBm RF output |
| Heat Dissipation |
Air cooling |
| Operating Temperature |
-4 °F to +131 °F (-20 °C to +55 °C) |
| Storage Temperature |
-4 °F to +185 °F (-20 °C to +85 °C) |
| Humidity |
< 95 % 77 °F (+25 °C) |
| Size |
5.03 in x 5.5 in x 0.9 in (128 mm x 140 mm x 24 mm) |
| Weight |
3.9 lb (1.8 kg) |
