Asset Track Pro Fixed Rfid Uhf Reader 32 Port Long Range Inventory Metallic Cover Integrated Antenna Uhf Integration

Description

Shell Material	Aluminum alloy
RF Interface	SMA outer nut head
Antenna Interface	32 ports
Working Frequency	902 MHz to 928 MHz (US) or 865 MHz to 868 MHz (EU)
Communication Port	RS232, RS485, Wiegand (standard), TCP/IP, WIFI, GPRS (selectable)
Protocol	(EPC C1 Gen2) ISO 18000-6C
Input/Output Port	2 channel relay output (selectable), 2 channel I/O input
Power	20 dBm to 30 dBm
Power Supply	12 V or 3 A
Development Package	Provide DEMO software, SDK & C#, VC, Java development routines
Another Configuration	1M/8M large capacity Flash storage, save when power down, POE power
Item Size	16.1 in x 10.6 in x 4.3 in (410 mm x 270 mm x 110 mm)
Net Weight	4.4 lb (2 kg)

Features

Protocol support: ISO 18000-6C (EPC C1 Gen2)

Software with different programming language allows easy upgrade

Support RS485, RS232, Wiegand26/34/32/26/66

The output power is adjustable up to 30dbm

Supporting various working modes such as timing mode

Master-slave mode and trigger mode

Waterproof and sunshine defending, idea for outdoor applications

Technical Specifications

Shell Material

Aluminum alloy

RF Interface

SMA outer nut head

Antenna Interface

32 ports

Working Frequency

902 MHz to 928 MHz (US) or 865 MHz to 868 MHz (EU)

Communication Port

RS232, RS485, Wiegand (standard), TCP/IP, WIFI, GPRS (selectable)

Protocol

(EPC C1 Gen2) ISO 18000-6C

Input/Output Port

2 channel relay output (selectable), 2 channel I/O input

Power

20 dBm to 30 dBm

Power Supply

12 V or 3 A

Development Package

Provide DEMO software, SDK & C#, VC, Java development routines

Another Configuration

1M/8M large capacity Flash storage, save when power down, POE power

Item Size

16.1 in x 10.6 in x 4.3 in (410 mm x 270 mm x 110 mm)

Net Weight

4.4 lb (2 kg)
