| Support Protocol |
ISO18000-6C (EPC CLASS1 GEN2) |
| Working Frequency |
902 MHz to 928 MHz (USA) or 865 MHz to 868 MHz (European) |
| Encryption |
Can encrypt directly, anti-copy |
| Transmit Power |
0 dbm to 30 dbm (Adjustable by software) |
| Software & SDK |
DEMO and C, VC, Java SDK |
| Anti-Thunder |
6000 V |
| Frequency Modulation |
Hopping or fixed frequency |
| Antenna |
12 dBi circular polarization |
| Interface |
WG 26 or 34; RS232; RS485; Customized –TCP/IP RJ45; WIFI |
| Case Material |
ABS |
| Power Supply |
Adapter (into +12 V DC) |
| Read Distance |
Up to 82.02 ft (Up to 25 m) (according to tag), can adjust by software |
| Read Prompt |
Buzzer |
| Storage Temp |
-40 °F to 212 °F (-40 °C to +100 °C) |
| Working Temp |
-4 °F to 176 °F (-20 °C to +80 °C) |
| Dimension |
9.25 in x 9.25 in x 2.24 in (235 mm x 235 mm x 57 mm) |
| Weight |
11.02 lb (5 kg) |
