| Working Frequency |
13.56MHz |
| Supported Protocols |
MifareClassic (MF1) NDEF, NfcV (15693), Ultraligh (MF0), IsoDep(quasi-CPU MF3), IsoDep (CPU) |
| Reading Distance |
0 to 1.97 in (0 to 5cm) |
| Cpu |
MT6272 12nm Octa-core Cortex-A53 2.0 GHz |
| Ram + Rom |
4GB RAM + 64GB ROM or 3GB RAM + 32GB ROM |
| Display |
5-inch IPS color display screen, resolution 720 x 1080 |
| Operating System |
Android 12 |
| Operating Temp. |
-4 °F to 140 °F (-20 °C to 60 °C) |
| Storage Temp. |
-104 °F to 158 °F (-40 °C to 70 °C) |
| Humidity |
5% RH to 95% RH non condensing |
| Drop Specification |
Multiple 3.9 ft. (1.2 m) drops (at least 30 times) to the concrete across the operating temperature range |
| Tumble Specification |
1000 x 1.64 ft. (0.5 m) falls at room temperature |
| Sealing |
IP67 per IEC sealing specifications |
| Dimension |
6.73 in x 3.19 in x 0.96 in (171mm x 81mm x 24.4mm) |
| Weight |
12.70 oz. (360g) |
