Description
Technical Specification
| Hard Drive Type | SSD + HDD |
| Video Memory Type | With the main memory |
| Operating System | Win 7 or 8 or 10 |
| Processor Type | J1900 or J4125 or i3, i5, i7 |
| Graphics Card Chipset | Integrated Card |
| HDD Rotation Speed | SSD |
| Processor Series | Intel Core I5 |
| Video Memory | 8 GB |
| Video Card | In-Tel H-D Graphics |
| Power | 15 W |
| RAM Type | DDR3 |
| Chipset Type | Intel H81 |
| Mouse & Keyboard | NO |
| Private Mold | NO |
| Hard disk interface | SATA2 |
| Graphics card interface | PCI-E |
| Chip type | HD5550 |
| WIFI | 2.4 GHz or 5.0 GHz Wi-Fi Optional |
| CPU | Quad Core I3 I5 I7 |
| LAN | 2 x RJ45 LAN |
| SSD | mSATA 128 GB, 256 GB, 512GB |
| Memory | 2 GB or 4 GB or 8 GB DDR3L 1333 MHz or 1600MHz 1.35 V 1 x 204-pim SO-DIMM, Maximum capacity 8 G |
| Hard Disk | SSD 1 x Full Height mSATA socket,16 GB or 30 GB or 60 GB or 120 GB or 240 GB or 500 GB or 1 TB mSATA SSD HDD Support SATA2.5″HDD |
| Support OS | Official Win11 or 10 or 8 or 7 or Linux or Ubuntu or CENTOS, etc. Notice we pre-install Win 7 or 8 or 10 or 11 OS for testing only, if you need legal genuine, win 7 or 8 or 10 or 11 OS or other OS like Linux, Ubuntu, Pf sense…, please contact us in time |
| Port | 4 or 2 x USB2.0, 4 x USB3.0, 2 x LAN, 1 x H-D,1 x VGA, 1 x AUD 1 x Switch |
| Audio | Main system Adopt Realtek ALC662 audio control chip, support dual channel, stereo, Line out |
| Extension | Mini-PCIE 1 x Half Height Mini PCIE for Wi-Fi or BT module |
| Power Requirement | DC 12 V 5 A (3 A) or 60 W (AC TO DC, 100 V to 240 V) |
| Working Environment | Operating Temperature -4 ℉ to 149 ℉ (-20 ℃ to 65 ℃) Storage Temperature 59 ℉ to 95 ℉ (15 ℃ to 35 ℃) Relative Humidity 5 % to 95 % (non-condensing) |
| Size | 7.5 in x 4.9 in x 2.12 in (192 mm x 125 mm x 54 mm) 5.3 in x 4.9 in x 1.5 in (135 mm x 125 mm x 40 mm) 7 in x 4.9 in x 2.16 in (180 mm x 125 mm x 55 mm) |
