Description
Features
- 6 in (39.62 cm) LCD, 1920 x 1080 Resolution
- Projected Capacitive Touch Screen
- Aluminium or Stainless-Steel Flush Bezel
- Intel i7-6600U
- Up to 8 GB DDR3 or Up to 16 GB DDR4 SO-DIMM
- Optional 2.5 in (6.35 cm) SSD
- Dual Gigabit Ethernet
- 4 x RS-232 or 422 or 485 BIOS Selectable
- 1 x 8-bit GPIO (4-bit Input, 4-bit Output)
- 1 x USB 3.0, 3 x USB 2.0 ports
Technical Specifications
| Display Size (Diagonal) | 15.6 in (39.62 cm) |
| Resolution | 1920 pixels x 1080 pixels |
| Backlight Lifetime | 50,000 hrs |
| Visual Characteristics | |
| Colors | 16.7 million |
| Aspect Ratio | 16:9 |
| Viewing Angle (VH) | 140° or 160° |
| Contrast Ratio | 700:1 |
| Brightness | 400 nits (Typical) |
| Touch Screen | |
| Technology | Projected Capacitive |
| Interface | USB |
| Driver | Windows 10 |
| Front Bezel | |
| Nema 4 | Aluminum |
| Nema 4x | Stainless Steel (Optional) |
| System | |
| CPU | intel i7-6600U15-6300u Celeron-3855U |
| Chipsets | Skylake |
| Memory | Up to 16 GB DDR4 SO-DIMM |
| Video Controller | Intel HD Graphics 520 |
| Video Interface | VGA |
| Storage Option | 2.5 in (6.35 cm) SSD |
| Compact Flash | Optional |
| Keyboard or Mouse | USB or PS2 |
