| Performance Specifications: Frequency Range |
840 MHz to 960 MHz, adjustable |
| Protocol |
EPC C1G2, ISO18000-6B/C |
| Chip |
Impinj R2000 |
| Frequency Band |
GB 920 MHz to 925 MHz, 840 MHz to 845 MHz; FCC 902 MHz to 928 MHz; |
| Optional Frequency Band |
Please tell our sales which band you want before ordering: ETSI 865 MHz to 868 MHz; JP 916.8 Mhz to 920.4 MHz; TW 922.25 MHz to 927.75 MHz; ID 923.125 Mhz to 925.125 MHz; RUS, 866.6 Mhz to 867.4 MHz; TEST, 802.75 MHz to 998.75 MHz; JP_LBT, 916.8 MHz to 920.8 MHz |
| Communication Protocol |
TCP/IP |
| Reading Distance |
0 ft to 65.6 ft (0 m to 20 m), adjustable |
| Antenna Gain |
9 dBi |
| Working Mode |
Fixed frequency or frequency hopping optional |
| RF Output Power (Port) |
33 dBm ±1 dBm (MAX) |
| Recognizing Dpeed |
>600 times per S |
| Physical Specifications: Communication |
COM port or network |
| RS232 |
Baud rate support 9600, 19200, 115200 (default), 460800 optional; |
| Physical Specifications: Material |
Aluminum |
| Installation Method |
Fixed with installation bracket |
| Power: Power Supply |
12 V or 3 A |
| Power Consumption |
20 W (output power 33 dbm) |
| Operating Environment: Operating Temperature |
-4 °F to 140 °F (-20 ºC to +60 ºC) |
| Storage Temperature |
-40 °F to 185 °F (-40 ℃ to +85 ℃) |
| Working Humidity |
< 95 % (77 °F (+25 °C)) |
| Dimension |
11.8 in x 11.8 in x 2.5 in (30 cm x 30 cm x 6.5 cm) |
| Net Weight |
6.6 lb (3 kg) |
