Description
Features
- Fast reading at 900 pcs per second
- IP 65 protected
- Power output 0-33 dBm
- Stable operating conditions over a long period
- Easy installation and deployment
- Support dense read and write, multi -label recognition, label data filtering, support RSSI, perceive signal strength
Technical Specifications
| Shell Material | Engineering Plastic ABS+Metal Die-Casting Aluminum |
| Protection Level | IP65 |
| Air Protocol | EPC Class 1 Gen2 (ISO 18000-6C) |
| Working Frequency | 860-960MHz |
| RF Output Power | 33dBm |
| Output Power Adjustment | 1 db |
| Antenna Gain | 8dbi |
| Antenna Specification | Embedded, circularly polarized |
| Consecutive Label Distance | 15 m |
| Continuous Writing Tag Distance | 0 to 3 m |
| Working Humidity | 10 % ～ 95 % Rh without condensation |
| Operating Voltage | DC 9 To 32 v |
| Operating Temperature | -4 °F To 158 °F (-20 ℃ To 70 ℃) |
| Storage Temperature | -4 °F To 158 °F (-20 ℃ To 70 ℃) |
| Weight | 4.4 lb (2kg) |
| Size | 14.37 in * 10.23 in * 3.34 in (365 mm × 260 mm × 85mm) |
