Description
Technical Specifications
| Protocol | ISO18000-6C (GB) |
| Frequency | 902 MHz to 928 MHz or 865 MHz to 868MHz (Adjustable) |
| Work Principle | FHSS or Fixed frequency |
| Work Mode | Timing or Active or Trigger |
| Antenna | Linear polarization |
| Gain | 12 dBi |
| Output Power | 33 dBm ±1 dB (MAX) |
| Communication Interface | RS232, RS485, USB, TCP/IP |
| Reading Distance | 98.4 ft (0 m to 30 m) (Adjustable) |
| Reading Speed | > 200 times pers |
| Working ParameterPower Supply | +9 V to +25 V, > 2 A |
| Power Dissipation | < 4 W per H |
| Work Tip | Buzzer |
| Temperature Range | 14 °F to 131 °F (-10 ℃ to +55 ℃) |
| Humidity Range | 20 % to 95 % （No condensation） |
