| Material |
ABS |
| Frequency |
840 MHz to 960 MHz |
| Protocol |
EPC C1 GEN 2 & ISO18000 6C |
| Communication |
Standard：RS-232, Ethernet (RJ45)Optional：WIFI, 4G, RS-485, WiegandCustomized：Bluetooth |
| Power Supply |
DC 12 V |
| Antenna |
9 dBi linear polarization antenna |
| Read Distance |
0 ft to 26.2 ft (0 m to 8 m) |
| Working Mode |
Passive |
| Multi-Tags Reading |
≥ 200 tags per s |
| IP Rating |
IP65 |
| Support Area |
China, Europe, North America, South Korea, Japan,Taiwan… |
| Output Power |
+5 dBm to +25 dBm |
| Output Power Flatness |
±0.2 dBm |
| Receiving Sensitivity |
-62 dBm |
| Radio Frequency Port Standing Wave |
≤ 1.5 |
| Interface Communication Rate |
115200 bps |
| Working Temperature Monitoring |
Support |
| Dense Reader Mode DRM |
Support |
| Antenna Connection Protection |
Support |
| Beep |
Support |
| RSSI |
Support |
| SDK |
Support |
| Working Temperature |
-22 °F to 158 °F (-30 °C to +70 °C) |
| Working Humidity |
5 % RH to 95 % RH |
| Storage Temperature |
-40 °F to 185 °F (-40 °C to +85 °C) |
| Size |
11.0 in x 11.0 in x 2.9 in (280 mm x 280 mm x 75 mm) |
