| Chipset |
SX 1276 |
| Supplier Type |
Original |
| Application |
M2M and IoT application |
| Product name |
Bluetooth Smart Home IOT GateWay |
| Type |
BLE Module |
| Bluetooth Protocol |
Bluetooth 5.0 |
| LoRaWAN Protocol |
LoRaWAN 1.0.2 B |
| LoRa Sensitivity |
-139 dBm at SF12, BW 125 kHz, 434 MHz / 470 MHz to 137 dBm at SF 12, BW 125 kHz, 868 MHz / 915 MHz |
| Bluetooth Distance |
984.25 in (25 m) sight distance |
| Indoor Tracking |
Bluetooth, 39.37 in (1 m) to 118.11 in (3 m) accuracy |
| Outdoor Tracking |
GNSS, 98.43 in (2.5 m) accuracy |
| Operating Temperature |
14 °F to 140 °F (-10 ℃ to 60 ℃) |
| Operating Current |
20 μA to 139 μA |
| G-sensor |
Supported |
| Encryption |
AES 128 |
