| Application |
M2M and IoT application |
| Product name |
Bluetooth Smart Home IOT GateWay |
| Type |
BLE Module |
| Bluetooth Protocol |
Bluetooth 5.0 |
| LoRaWAN Protocol |
LoRaWAN 1.0.2 B |
| LoRa Sensitivity |
-139 dBm, SF12, BW 125 kHz, 434 MHz/ 470 MHz -137 dBm @SF12, BW 125 kHz, 868 MHz/915 MHz |
| Bluetooth Distance |
~82 ft (25 m) sight distance |
| Indoor Tracking |
Bluetooth, 3.28 ft (1 m) to 9.84 ft (3 m) accuracy |
| Outdoor Tracking |
GNSS, 8.2 ft (2.5 m) accuracy |
| Operating Temperature |
14 °F to 140 °F (-10 ℃ to 60 ℃) |
| Operating Current |
20 μA to 139 mA |
| G-sensor |
Supported |
| Encryption |
AES128 |
