Description
Overview
Asset Track Pro LoRaWAN Hardware features Edge and Fog computing capabilities with Python programming, rich serial interface and free embedded NS, available in CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923 global frequency.
Features
- Internal Antenna Design
- Embedded Network Server
- Built-in supercapacitor
Technical Specifications
| Hardware | Processor | Quad-core 1.5 GHz, 64-bit ARM Cortex-A53 |
| Memory | 512 MB DDR4 RAM | |
| Ingress Protection | IP67 | |
| Connectivity | Frequency Band | CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923 |
| Channel | 8 | |
| Wi-Fi | IEEE 802.11 b/g/n | |
| Ethernet | 1 x 10 Mbps /100 Mbps /1000 Mbps | |
| Network Server | Embedded | Yes |
| 3rd Party’s | TTN, LORIOT, ThingWorx | |
| Capabilities | Nodes Connection | Up to 2000 |
| Radio Range | Up to 10 km (about 6.21 mi) |
