| Frequency |
13.56MHz |
| Protocol |
ISO14443A |
| Read Distance |
1.18 in to 3.93 in (3cm to 10cm) |
| Working Mode |
Passive |
| Working Voltage |
DC 3.7V to 4.2V |
| Battery Capacity |
1400mAh |
| Charging Power |
DC 5V – 500mAh |
| Power Consumption |
<0.8w |
| Antenna |
Built-in |
| Card Reading Time |
0.1s |
| Bluetooth Communication Distance |
32.80 ft. to 49.21 ft. (10m to 15m) |
| Bluetooth Specifications |
Class 2, GAP, SDAP, SPP, GOEP |
| Communication Baud Rate |
9600bps |
| Status Indication |
Buzzers and indicators |
| Charging Interface |
Micro USB |
| Charging Time |
30 minutes |
| Working Duration |
24 hours of continuous work |
| Stand-By Time |
10 days |
| Supporting Cards |
MIFARE 1K, Ultralight EV1, Ntag213, etc. |
| Support System |
Android |
| Card Reading Mode |
Auto reading, external trigging reading (continuous pressing keys for 3 seconds can automatically switch) |
| Operating Temperature |
-4°F to 149°F (-20 ℃ to + 65 ℃) |
| Operating Humidity |
5% to 90% without compression |
| Size |
3.26 in x 2.04 in x 1.01 in (83mm x 52mm x 25.8mm) |
| Weight |
3.45 oz. (98g) |
