Description
Technical Specifications
| Working Frequency | 13.56 MHz |
| Reading Distance | 0 in to 1.18 in (0 mm to 29.97 mm) |
| Communication Interface | UART 3.3 V TTL signal interface |
| Serial Port Baud Rate | 115,200 bps, no parity, 8 data bits, 1 stop bit |
| Power | DC 5 V |
| Reading Current | 0.1 A |
| Stand-by Current | 0.04 A |
| Working Temperature | -4 °F to 140 °F (-20 °C to 60 °C) |
| Storage Temperature | -22 °F to 158 °F (-30 °C to 70 °C) |
| Storage Humidity | 5% RH to 95% RH (no condensation) |
| Size | 2.36 in x 1.57 in (60 mm x 40 mm) |
| Weight | 0.02 lb (10 g) |
