Description
Overview
13.56 MHz Frequency. Multi-Block Read and Write. 2.52 in X 2.20 in X 0.27 in Dimensions. Compatibility of MF, MF Ultralight, MF DESFire, and NFC Tag.
Features
- High-Speed Data Transfer
- High Data Integrity
- Anti-Collision
- Multi-block Read and Write
- Intercom System
- Handheld RFID Reader
- POS System
Technical Specifications
| Frequency | 13.56 MHz |
| Support Communication Interface | USB or UART or ABA or RS 232 |
| Power Input | DC 3.3 V or 5 V or 12 V or 18 V |
| Reading Range | 2.36 in to 2.75 in (6 cm to 7 cm) |
| Protocol | ISO 14443-A or 14443-B or 15693 |
| Temperature | 14 °F to 158 °F (10 °C to 70 °C) |
| Dimension | 2.52 in X 2.20 in X 0.27 in (64 mm X 56 mm X 7 mm) |
| Weight | 0.37 oz (10.6 g) |
