Description
Features
- Support ISO18000-6C EPC Gen2
- IMPINJ R2000 CHIP
- Support stand-alone mode
- Support RS232, Wiegand 26/34, TCP/IP interfaces
- GPIOs
- IP68
- Read distance up to 12 meters
- Customer’s choice of Linear or Circular antenna
Technical Specifications
| Frequency | 860-960mhz |
| Protocol | ISO 18000-6C |
| Interface | Wiegand, RS232, TCP/IP |
| Type | UHF Integrated Reader |
| Chip | INDY Impinj R2000 |
| IP Rate | IP68 |
| Operating Temperature | -4°F to 131°F (-20 °C to 55 °C) |
| Storage Temperature | -40°F to 176°F (-40 °C to 80 °C) |
| Dimensions | 1.71 in * 17.71 In *1.57 In (450 x 450 x 40 mm) |
| Weight | 3.30 lb (1.5 Kg) |
