Description
Technical Specifications
| Working Frequency | 13.56Mhz |
| Protocol | ISO 14443A, ISO 15693 |
| Reading Distance | 3.93 in (10cm) |
| Communication Interface | SPI interface, I2C interface, Serial UART interface |
| Serial Port Baud Rate | 115200 bps no parity, 8 data bits, 1 stop bit |
| Power | DC 5V |
| Reading Current | 100mA |
| Stand-By Current | 40mA |
| Working Temp. | -22°F to 176°F (-30℃ to 80℃) |
| Storage Temp. | -40°F to 194°F (-40℃ to 90℃) |
| Storage Humidity | 5% to 95%RH no condensation |
| Size | 1.18 in x 1.57 in (30mm x 40mm) |
| Weight | About 0.35 oz. (10g) |
