Description
Features
- Wide Protocol Support
- Adjustable Reading Distance
- High Speed Communication
- Low Power Consumption
- Versatile Temperature Range
- Compact Design
- Lightweight
- Robust Pin Configuration
Technical Specifications
| Reading Distance | 0 cm to 5.91 in (0 cm to 5 cm) |
| Protocol | ISO 14443A |
| Frequency | 13.56 MHz |
| Communication Interface | RS 485 |
| Serial Port Baud Rate | 115200 bps, No parity, 8 Data bits, 1 Stop bit |
| Power | DC 5 V |
| Standard Protocol | ISO 14443-A |
| Temperature | -4 °F to 140 °F (-20 ℃ to 60 ℃) |
| Dimension | 7.87 in X 6.30 in X 1.57 in (199 mm X 160 mm X 39 mm) |
| Weight | 17.63 oz (500 g) |
