Description
Overview
Asset Track Pro smartcard reader industrial tablets & PC’s due to its convenience and ultra-security benefits, mobile identity is playing an increasingly important role in everyone’s daily life. Fingerprint and other biometric applications are widely applied in election, telecom, banking, social insurance, border control, access control, time attendance, law enforcement and other applications. Based on its abundant engagement in biometric-related applications like election, telecom, banking, low enforcement and rich field experience gained from former projects, Asset Track Pro listened a lot about the customer’s need, designed and developed its next-generation biometric device: Smartcard Reader, brought with enhanced usability and robustness to ensure seamless enrollment, ID verification and identification on the spot.
Features
- Compact, lightweight, stable design
- Advanced biometric technology integration
- FBI PIV-certified fingerprint sensor
- Multi-functional contactless card reader
- High-resolution camera with barcode reading
- Iris scanner for verification
- Long-lasting 5000 mAh battery
- Enhanced security with PSAM card
- 4G, Wi-Fi, BT, dual SIM slots
Technical Specifications
| Operating System | Android 11 |
| CPU | 1.8 GHz to 2.0 GHz, Quad Core |
| Memory | 2 GB RAM, 16 GB ROM (3 GB RAM + 32 GB ROM available) |
| Camera | Rear 8.0 M Pixels, Auto Focus with
Dual Flash (13 MP could be customized), Front 5.0 M Pixels |
| Memory and Extension | Micro SD Card, up to 128 GB |
| GPS | GPS, GLONASS supported, 32.80 ft (10 m) |
| BT | BT 5.0 LE |
| WIFI | IEEE 802.11b or g or n |
| Display | 5 in (12.7 cm) IPS Display, Resolution 1280 pixels x 720 pixels |
| Panel | Capacitive touch screen |
| PSAM Card | 1 PSAM card slot |
|
Networks |
GSM: 850 or 900 or 1800 or 1900 WCDMA: B1 or B2
CDMA: BC0 TDS-CDMA: B34 or B39 |
| RFID (Optional) | 14443A or B, mifare s50s70, FM1208 CPU |
|
Fingerprint Scanner |
500dpi or 256 gray resolution, image Size: 300 x 400 pixels, WSQ Compression available, ISO197942, ANSI378 template, FBI PIV, FBI Mobile ID FAP20, IP65 certified, Image Format ISO19794-4, support live finger detection, work under direct sunlight available. |
| Contact Card Reader (Optional) | FM Cos Card, ISO7816 |
| Iris Scanner (Optional) | ISO or IEC 19794-6 and ISO 8583, Capture Mode: single iris, Capture Speed: <1 s Capture Distance: 0 in to 0.78 in (0 cm to 2 cm) (eyes to patch) FRR: <0.1% FAR: <0.0001% |
| Battery Pack | 3.7 V, 5000 mAh |
| USB | Mini- USB 10 pin |
| Voice Call | Supported |
| Reliability | MTBF no less than 5000 hrs |
| Peripheral | Hand Stripe |
| Speaker | Supported |
| Charging interface | DC 5 V 1.5 A |
| Operating Temp | 32 °F to 122 °F (0 ℃ to 50 ℃) |
| Storage Temp | 14 °F to 140 °F (-10 ℃ to 60 ℃) |
| Working humidity | Working humidity |
| Storage humidity | 5% to 90% RH |
| Dimensions | 7.16 in x 3.18 in x 0.98 in (182 mm x 81 mm x 25mm) |
| Weight | 0.80 lb (365 g) (Including Battery) |
