| Frequency |
920 MHz to 925 MHz or 902 MHz to 928 MHz or 865 MHz to 868 MHz |
| Protocol |
EPC Class 1 Gen2, ISO18000-6C |
| RF Output Power |
33 dBm ± 1 dB (MAX) |
| Antenna |
4 TNC antenna interface |
| Modulation |
DSB-ASK |
| Consecutive label distance (Reading EPC Code) |
0 ft to 32.8 ft (0 m to 10 m) (related to the performance of the tag chip), using a 9dBi antenna, with a read success rate of greater than 95 % in a non-interfering environment |
| Continuous writing tag distance (Write EPC code) |
0 ft to 16.4 ft (0 m to 5 m) (related to the performance of the tag chip), using a 9dBi antenna, with a read success rate of greater than 90 % in a non-interfering environment |
| Power Supply |
DC 24 V or 2.5 A (DC 9 V to 30 V,60 W) or POE (IEEE 802.3 af or at or bt) |
| Support |
Support secondary development |
| Color |
Silver |
| Output Power Adjustment |
1 db step walking |
| External Communication Interface |
TCP or IP, RS232, optional wifi, BT, 4G and other communication modes |
| Operating Voltage |
DC 12 V or 2 A (DC 9 V to 30 V，24W) or POE (IEEE 802.3 af/at/bt) |
| Working Humidity |
10 % to 95 % without condensation |
| Operating Altitude |
Max (4500 m) 15000 ft |
| Operating Temperature |
-4 °F to 158 °F (-20 °C to 70 °C) |
| Storage Temperature |
-40 °F to 185 °F (-40 °C to 85 °C) |
| Size |
7.4 in x 4.3 in x 1.4 in (188.5 mm x 110 mm x 37.5 mm) |
| Weight |
1.5 lb (0.72 kg) |
