| Frequency |
902 MHz to 928 MHz or 865 MHz to 868 MHz |
| Protocol |
EPC Global UHF Class 1 Gen2 or ISO 18000-6 c |
| Interface |
RS232 or WG26 or USB or RELAY or TCP/IP (optional) |
| Read Range |
3.2 ft to 32.8 ft (1 m to 10 m) |
| Built-in Antenna |
9 dBi circular antenna |
| Work Mode |
Active or trigger or answer or password or mask mode |
| Application |
Parking people access warehouse management etc |
| Software Support |
Provide SDK, demo software |
| Material |
ABS |
| Output Power Range |
0 dBm to 26 dBm |
| Read Range |
3.2 ft to 13.1 ft (1 m to 4 m) |
| Power Supply |
9 V to 36 V |
| Operating Temperature |
14 °F to 131 °F (-10 ℃ to 55 ℃) |
| Storage Temperature |
-4 °F to 167 °F (-20 ℃ to 75 ℃) |
| Dimensions |
6.4 in X 6.4 in X 1.1 in (165 mm × 165 mm × 30 mm) |
| Weight |
1.6 lb (0.75 kg) |
