| Working Frequency |
860 MHz to 960 MHz 902 MHz to 928 MHz 865 MHz 868MHZ |
| Protocol |
ISO18000-6C (EPC G2) or ISO-18000-6B |
| Reading Range |
0 ft to 16.4 ft (0 m to 5 m) |
| Antenna Gain |
8 dBi circular polarization |
| Power Supply |
12 V or 3 A |
| Input or Output Port |
2 channel relay output (selectable) and 1 channel trigger input |
| Software |
Demo software |
| Communication Interface |
Wiegand 26 or 34 or 42 TCP or IP RS232 (WIFI or RS485 is customized) |
| Input or Output Interface |
1 way trigger input or 2 way relay output(customized) |
| Working Distance |
9.84 ft to 19.68 ft (3 M to 6 M) |
| Shell Material |
ABS |
| Communication Port |
RS232 and RS485 and Wiegand(standard) and TCP or IP and WIFI and GPRS (selectable) |
| Development Package |
Provide DEMO software and SDK and C# and VC and Java development routines |
| Item Size |
11.02 in x 11.02 in x 1.57 in (280 mm x 280 mm x 40 mm) |
| Net Weight |
6.61 lb (3 kg) |
