Description
Features
- Integrated structure design, beautiful appearance, suitable for outdoor
- Integrate high performance linear polarized antennas
- Recognize the long range distance stably
- Supports tag echo signal detection, tag data filtering, clock stamping
- Supports input and output functions
- Recognition speed is fast
- The identification of single label can reach 140 times per second
Technical Specifications
| Working Frequency | 865 MHz to 868 MHz (EU standard) and 902 MHz to 928 MHz (US standard) |
| Supported Protocols | ISO18000-6B，ISO18000-6C(EPCGEN2) |
| Communication Ports | N: Wiegand26/34/98 RS485RS232USB E:Wiegand26/34/98RS232TCPUSB |
| Input Interface | 1 way trigger input |
| Polarization Mode | Circular polarization |
| RF Power | 0 dBm to 30 dBm |
| Reading Range | 0 ft to 26.25 ft (0 m to 8 m) |
| Antenna | 9 dbi circular antenna |
| Power Supply | DC + 9 V |
| Operation Temperature | – 4 °F to 158 °F (- 20 ℃ to + 70 ℃) |
| Size | 10.16 in x 10.16 in x 2.21 in (258 mm x 258 mm x 56 mm) |
| Weight | 3.86 lb (1.75 kg) |
