Description
Features
- Circular polarization
- DC ground lightning protection
- Reading range 0.66 ft to 16.4 ft (0.2 m to 5 m)
- SMA Female connector
Technical Specifications
| Frequency | 860 MHz to 960MHz |
| Protocol | ISO 18000-6C |
| Polarization | Circular |
| Air Interface Protocol | EPC C1G2 |
| Gain | 5 dBi |
| Voltage Radio Wave Rate | ≤ 1.4 |
| F/B Ratio | ≥ 20 |
| Impedance | 50 Ω |
| Maximum Power | 50 W |
| Operating Temperature | – 40 °F to 158 °F (- 40 °C to 70 ℃) |
| Dimension | 4.72 in x 4.72 in x 0.31 in (120 mm x 120 mm x 8 mm) |
| Net weight | 0.66 lb (0.3 kg) |
