Description
Features
- Linear polarization
- Directional radiation direction
- Aluminum radiation material
- N Female connector
- ABS radome material
- IP65 protection grade
Technical Specifications
| Frequency | 900 MHz to 930 MHz |
| Gain | 10 dBi |
| VSWR | ≤ 2.0 |
| Polarization | Linear |
| Radiation Direction | Directional |
| Horizontal Beamwidth | 70 Deg (± 1 Deg) |
| Vertical Beamwidth | 60 Deg (± 2 Deg) |
| Input Impedance | 50 Ω |
| Power | 50 W |
| Color | White |
| Radiation Material | Aluminum |
| Connector Type | N Female |
| Radome Material | ABS |
| Protection Grade | IP65 |
| Working Temperature | – 40 °F to 131 °F (- 40 ℃ to + 55 ℃) |
| Size | 21.65 in x 9.06 in x 1.57 in (550 mm x 230 mm x 40 mm) |
| Gross weight | 29.98 oz ± 0.35 oz (850 g ± 10 g) |
