| Frequency |
860 MHz to 960 MHz |
| Protocol |
EPC Global UHF class1 Gen2 or ISO 18000-6 |
| Reading Distance |
0 ft to 82.0 ft (0 m to 25 m) |
| Power Supply |
With 220 V AC input, the output of +12 V or 3A DC power converter |
| Software |
Provide demo software and API based Android or iOS platform system |
| Certificates |
CE FCC RoHS |
| Shell Material |
Die cast aluminum alloy |
| Operating System |
Android 7.1.2 |
| CPU Processor |
Qualcom platform, 1.8 GHz quad core A7 processor, with a main frequency of up to 1.8 GHz |
| GPU Graphics Processor |
GPU and supports 4K and H.265 hard decoding |
| Antenna Detector |
Support |
| RAM + ROM Memory |
1 GB LPDDR3+ 8 GB eMMC |
| Built In Storage SD |
Supports SD card X 1, up to 128 GB |
| USB Interface |
2 USB 2.0 interfaces (HF terminals), 1 debugging interface OTG (TYPE-C) |
| HDMI |
Support video 1 X HDMI interface (1080 P) |
| Type-C |
OTG, external debugging interface |
| Input Voltage |
DC 12 A or 3 A |
| Power |
25 W |
| Environmental Temperature Detection |
Support |
| I/O Interface |
With 4 upto coupler inputs (initial low level) and 4 relay output ports (capable of loading DC 24 V or 2 A) |
| WIFI |
Support IEEE802.11n or b or g 2 .4 G |
| Bluetooth |
Support Bluetooth 4.0 |
| 4G |
4G: Mobile (TD-LTE); 4G: China Unicom (FDD-LTE); 4G: Telecommunications (FDD-LTE); 4G: China Unicom (TD-LTE) |
| Serial Port |
1-channel serial communication |
| Network Connection |
10 M or 100 BASE-T Ethernet |
| SIM Card Interface |
1 |
| RF Interface |
4-channel SMA antenna interface |
| Reliable Firmware Upgrade |
Scalable upgrade mechanism |
| Application Software Interface |
Provides API development packages and C and Java application routines |
| Output Power |
0 dBm to 33 dBm ±1 dBm |
| Receiving Sensitivity |
＜﹣85dBm |
| Tag Recognition Peak |
＞800 times per second |
| Writing Distance |
0 ft to 32.8 ft (0 m to 10 m) |
| Working Temperature |
-4° F to 149° F (﹣20 °C to﹢65 °C) |
| Storage Temperature |
-40 °F to 185 °F (﹣40 °C to﹢85 °C) |
| Environmental Humidity |
＜95 % (non-condensing state) |
| Dimension |
9.4 in X 4.5 in X 1.2 in (240 mm x 115 mm x 33 mm) |
