| Frequency |
860 MHz to 960 MHz |
| Protocol |
EPC global UHF Class 1 Gen 2 (ISO 18000-6C) |
| Communication Interface |
RFID |
| Chip |
NXP UCODE 9, Fudan 51E or 11E |
| Special Features |
Waterproof or Weatherproof, UV Protection, Strong Adhesive, Printable |
| EPC Memory |
96 bits |
| Material |
PET |
| Read Range |
Up to 59.0 ft (18 m) |
| Work Mode |
Passive |
| Customized Support |
Customized logo and EPC encoding |
| Application |
Vehicle windshield |
| Applicable Surface Materials |
Windshield, plastic, cardboard, glass, etc. |
| Tag Material |
Printable PET (thermal transfer) + inlay |
| Recommendation Ribbon |
Resin ribbon |
| Attachment Method |
Strong double-sided adhesive |
| Inlay Size |
3.7 in X 0.9 in (94 mm X 24 mm) |
| Tag Size |
3.8 in X 1.0 in (98 mm X 27 mm) |
