| Frequency |
902 MHz to 928 MHz |
| Protocol |
EPC C1 GEN2 / ISO18000-6C |
| Communication |
Blue tooth and USB |
| Reading Distance |
3.2 ft to 26.2 ft (1 m to 8 m) |
| SDK |
Android or IOS SDK Supported |
| Battery Capacity |
2000 mAh |
| Charging Duration |
2 hrs |
| Data Collection |
UHF RFID |
| Keypad |
ON or OFF, SCAN |
| Indicator LED |
Red indicator will be ON when charging. Green indicator will be ON when device has been fully charged. Blue indicator will be ON when battery is higher than 20%. Blue indicator will flash when battery is lower than 20%. BT is not paired when BT indicator is OFF. BT is paired when BT indicator is ON |
| Port |
Type C USB |
| Charging Current |
5 V or 1.5 A |
| Security |
RFID Encrypted Module |
| Power |
1 W |
| Antenna |
Circular Polarized antenna (3 dBic) |
| R/W Range |
29.5 ft (> 9 m) |
| Fastest Read Rate |
900+ tags per s |
| Drop Specification |
3.9 ft (1.2 m) dropping on concrete |
| Operating Temperature |
-4 °F to 122 °F (-20 ℃ to 50 ℃) |
| Storage Temperature |
-40 °F to 158 °F (-40 ℃ to 70 ℃) |
| Humidity |
5% RH to 95% RH (non-condensing) |
| Dimension |
4.2 in X 3.0 in X 0.7 in (108 mm X 78 mm X 18 mm) |
| Weight |
7.0 oz (200 g) |
