| Working Voltage |
1.8 V to 3.7 V |
| Acceptable Current |
10 mA to 14 mA |
| Transmit Current |
120 mA at 20 dBm, 90 mA at 17 dBm, 29 mA at 13 dBm |
| Operating Frequency |
868 MHz / 915 MHz |
| Transmit Power |
+20 dBm |
| Receive Sensitivity |
-139 dBm at LoRa & 62.5 KHz & SF = 12 & 146 bps |
| -136 dBm at LoRa & 125 KHz & SF = 12 & 293 bps |
| -118 dBm at LoRa & 125 KHz & SF = 6 & 9380 bps |
| -123 dBm at FSK & 5 KHz & 1.2 Kbps |
| Frequency Error |
+ / -15 KHz |
| FIFO Space |
64 Bytes |
| Data Rate |
1.2 Kbps to 300 Kbps at FSK |
|
0.018 Kbps to 37.5 Kbps at LoRa |
| Interface Form |
SPI |
| Sleep Current |
0.2 uA at SLEEP |
|
1.5 uA at IDLE |
| Operating Temperature |
-40 °F to 185 °F (-40 °C to 85 °C) |
