| MOQ |
1 Piece for Industrial Embedded PC |
| CPU |
Intel Core I3 or i5 or i7 for Industrial Embedded PC |
| Operating System |
Windows 7,8,9,10 and Linux for Industrial Embedded PC |
| Certification |
CE for Industrial Embedded PC |
| Chipset |
Intel Z170 |
| Internal Memory |
Technology: Dual Channel DDR4 at 1.2V1886 or 2666MHZ |
| Max Support |
32GB |
| Slot |
2 x 260pin SO-DIMM |
| Graph |
Chipset: Intel Z170 |
| CRT |
VGA |
| HDMI |
HDMI1.4,1920×1200 at 60 Hz |
| Ethernet LAN1 |
10 or 100 or 1000 Mbps Intel i211 Ethernet card |
| Ethernet LAN2 |
10 or 100 or 1000 Mbps Intel i211 Ethernet card |
| Audio Frequency |
Interface: Realtek ALC662 High fidelity audio source input microphone input |
| I/O Interface Serial |
2xRS-232 port (COM1-COM2), COM1, COM2 |
| I/O Interface Optional |
Available as RS422, RS485, COM3-COM4 Optional |
| USB |
4 x USB 3.0 port, 4 x USB2.0 |
| DIO |
16 bit optical isolation GPIO (8 IN, 8 out) Optional |
| Extend Expansion Card Slot |
2 expansion slots 1PCI+1PClex16 or 1PCIEX1+1PCIEx16 |
| HDD |
Single 2.5-inch hard drive bracket |
| SSD |
1xM.2 (M.2 with PCIE signal support) |
| Microsoft Software |
Windows 7, Windows 8, Windows 10 |
| Linux Software |
Ubuntu 12.04 |
| Voltage input |
9-36V wide voltage |
| Power Demand Power Adapter |
AC to DC, DC9-36V, 180W or more |
| Structure |
Aluminum + plate gold shell |
| Machine Size |
9.06 in × 7.56 in × 3.07 in |
| Operating Temperature |
-4 °F to -67 °F |
| Storage Temperature |
-40 °F to -121 °F |
| Working Humidity |
95% |
