| Screen |
Industrial-Grade 5 in LCD Display |
| Control |
Single-Chip Microcomputer, Keyboard Operation |
| Functions |
Distance, Speed, Resistance Measurement |
| Sampling Method |
Flashover Sampling, Low-Impulse Method |
| Sampling Frequency |
30 MHz, 60 MHz, 120 MHz |
| Test Distance |
Up to 102.5 mi (165 km) |
| Pulse Width |
0.2 µs to 9.9 µs |
| Deviation |
No More Than ± 0.25% |
| Pre-locating Accuracy |
Absolute ± 32.8 ft (10 m); Relative ±1% |
| Power Supply |
Built-in 2.6 V / 10.4 Ah DC Battery; External AC 220 V 50 Hz |
| Battery Type |
Nickel Hydrogen with Charger |
| Printer |
Built-in Micro Printer for Waveforms and Reports |
| Waveform Functions |
Left/Right Displacement, Compression for Clarity |
| Computer Communication |
Compatible for Data Transfer |
| Data Storage |
Stores up to 10 Test Waveforms |
| Operating Temperature |
-13 °F to 149 °F (-25 °C to 65 °C) |
| Monitor Viewing Angle |
>160° |
| Test Mode |
Low Pressure Plus, Multiple Pulse, Voltage Sampling |
| Dimensions |
16.9 in × 14.2 in × 9.1 in (43 cm × 36 cm × 23 cm) |
| Weight |
17.6 lbs (8 kg) |
