| Screen |
Industrial-grade 5.7-inch two-color display |
| Control |
Single-chip microcomputer, push-button operation |
| Anti-Interference |
Strong anti-interference ability |
| Functions |
Distance, speed, and resistance measurement |
| Printer |
Integrated micro printer for test waveforms and reports |
| Sampling Method |
Low voltage pulse and flashover sampling |
| Sampling Frequency |
100 MHz |
| Pulse Amplitude |
35 V |
| Pulse Width |
0.2 µs to 2 µs |
| Minimum Resolution |
3.28 ft (1.0 m) |
| Dead Zone |
≤114.8 ft (35 m) |
| Distance Detection Range |
≥19.88 mi (32 km) |
| Measurement Error |
≤±(0.5% × L + 3.28 ft (1 m)) |
| Communication Interface |
RS232 |
| Power Supply |
Charge AC 110 V to 240 V, 50 Hz / 60 Hz; Built-in 5200 mAh battery |
| Protection Level |
IP54 |
| Working Condition |
-4 °F to 149 °F (-20 °C to 65 °C), RH ≤90% |
| Size |
14.1 in × 11.2 in × 6.6 in (35.8 cm × 28.4 cm × 16.8 cm) |
| Weight |
10.14 lbs (4.6 kg) |
