| Test Methods |
Low voltage pulse, flashover method, Audio Method, Acoustic Magnetic Synchronization Method |
| Test Range |
37,2823 mi (60 km) Max, 49.21 ft (15 m) Min |
| Detection Depth |
6.56 ft to 16.4 ft (2 m to 5 m) |
| Measurement Accuracy |
± 32.81 ft (10 m) (rough), ± 0.66 ft (0.2 m) (precision) |
| Sampling Frequency |
400 MHz |
| Minimum Resolution |
1.64 ft (0.5 m) |
| Pulse Amplitude |
100Vpp |
| Pulse Width |
0.1 μS and 2 μS |
| Output Power |
Path Power: 100W; Impact Power: 0 to 400W |
| Short Circuit Current |
0 mA to 100 mA |
| Burn Through Power |
0 J to 900J |
| Power Supply |
12 V / 10 Ah DC (built-in, continuous for 10 hours) |
| Display |
12-Inch Industrial Grade All-in-One LCD Display |
| Control Mode |
Touch Operation, Windows Operating System |
| Operating Temperature |
14 °F to 122 °F (-10 °C to 50 °C) |
| Weight |
26.46 lbs (12 kg) |
