Description
Features
- Continuous Square Wave Signal
- High Sampling Frequencies Supported
- Audio Signal Transmission Capability
- Wide Test Range Coverage
- Precise Deviation Accuracy
Technical Specifications
| Working Mode | Continue Square Wave Signal |
| Output Signal | Audio |
| Receive Signal | Audio |
| Output Power | 100 W |
| Working Power Supply | 220 V (±10%), 50 Hz (±5%) |
| Test Mode | Low-pressure Pulse, Multiple Pulse, Voltage Sampling, etc. |
| Sampling Frequency | 98.4 feet (30 M), 196.8 feet (60 M), 393.7 feet (120 M) |
| Test Distance | Up to 102.5 mi (165 km) |
| Test Pulse | 0.2 μs to 9.9 μs |
| Deviation | No more than ±0.25% |
