| Accuracy |
0.2 m (0.66 ft) |
| Output Frequency |
1 Hz |
| Open Circuit Voltage |
0 V 2800 V (pulsating DC, peak 8kV) |
| Short Circuit Current |
0 mA to 35 mA (pulsating DC, peak 100 mA) |
| Wireless Communication Distance |
98.43 ft (30 m) minimum |
| Transmitter Power Supply |
AC 220 V mains, generator connection possible (output power ≥ 1500 W) |
| Transmitter Power |
900 W max |
| Sensor Power Supply |
3 x 7 alkaline dry batteries |
| Receiver Power Supply |
5 x 5 alkaline dry batteries |
| Operating Humidity |
5% to 90% RH |
| Altitude |
< 14764.9 ft (< 4500 m) |
| Operating Temperature |
14 °F to 104 °F (-10 °C to 40 °C) |
| Transmitter Size |
17.91 in x 13.19 in x 12.2 in (45.5 cm x 33.5 cm x 31 cm) |
| Sensor Size |
7.09 in x 3.94 in x 1.38 in (18 cm x 10 cm x 3.5 cm) |
| Receiver Size |
8.07 in x 3.94 in x 1.38 in (20.5 cm x 10 cm x 3.5 cm) |
| Weight (Transmitter) |
15 kg (33.07 lbs) |
| Weight (Sensor) |
0.45 kg (0.99 lbs) |
| Weight (Receiver) |
0.45 kg (0.99 lbs) |
