| Display Method |
21-inch industrial-grade LCD touch screen (XP operating platform) |
| Storage Method |
8 GB |
| Test Method |
Low voltage pulse, multiple pulse, lightning surge methods |
| Operation Mode |
Dual operation using touch pen and touch mouse |
| Test Distance |
Not less than 37.28 miles (60 km) |
| Shortest Test Distance (Blind Spot) |
0 ft to 16.4 ft (0 m to5 m) or no blind spots |
| Accurate Fixed Point Error |
± 0.66 ft (± 0.2 m) |
| Test Error |
System error less than ± 1% |
| Multiple Pulse Generator |
Impulse voltage ≤ 40 kV |
| Resolution V/Fm |
V: Wave propagation velocity (m/µs); software cursor: 0.33 ft (0.10 m) |
| Instrument Sampling Frequency |
6.25 MHz, 12.5 MHz, 25 MHz, 50 MHz, 100 MHz |
| Power Supply and Consumption |
AC220V ± 10%; ≤ 15 W; DC12V (7Ah); ≤ 20 W |
| Standby Time |
Continuous operation for approximately 6 hours |
| Ambient Temperature |
14 °F to 104 °F (-10 °C to 40 °C). |
| Temperature Range |
-4 °F to 104 °F (-20 °C to 40 °C). |
| Relative Humidity |
≤ 80% |
| Overall Dimensions |
7.09 in × 11.81 in × 15.75 in (18 cm × 30 cm × 40 cm) |
| Host Weight |
13.67 lbs (6.2 kg) |
