| Impact High Voltage |
0 kV to 35 kV (optional) |
| High Voltage Divider Accuracy |
Level 1.5 |
| Built-In Capacitance |
4 μF |
| Discharge Power |
0 J to 2450 J |
| Charge Current |
320 mA |
| Output Voltage Polarity |
Negative polarity |
| Impact Power |
400 W |
| Overcurrent Protection |
16 A (more than 3 seconds) |
| Overtemperature Protection |
185 °F (85 °C) |
| Working Power Supply |
AC 220V ±10% / 50Hz ±2Hz |
| Ambient Temperature |
-4 °F to +140 °F (-20 °C to +60 °C) |
| Display |
Industrial-grade 5 in LCD |
| Measurement Functions |
Distance, speed, and resistance measurement |
| Sampling |
Automatic continuous sampling without losing discharge waveforms |
| Testing Methods |
Flashover sampling and low-impulse method |
| Distance Measurement Range |
Maximum: 37.2823 mi (60 km); Minimum: 49.2 ft (15 m) |
| Pre-Locating Accuracy |
Absolute: ±32.8 ft (10 m); relative: ±1% |
| Built-In DC Power |
2.6V / 10.4Ah, with optional external AC 220V / 50Hz power supply |
| Volume |
16.9 in × 13.6 in × 21.5 in (43 cm × 34.5 cm × 54.5 cm) |
| Weight |
Not more than 88.2 lbs (40 kg) |
