| Rated Voltage |
80kV (peak) |
| Load Capacity |
0.1Hz, ≤0.5µF; 0.05Hz, ≤1.0µF; 0.02Hz, ≤2.5µF; 0.01Hz, ≤5.0µF |
| Fuse |
25A |
| Useful Applications |
Cables (35kV and below), Generators |
| Output Frequency |
0.1Hz, 0.05Hz, 0.02Hz, 0.01Hz |
| Loading Capability |
0.1Hz max 0.5µF; 0.05Hz max 1.0µF; 0.02Hz max 2.5µF; 0.01Hz max 5.0µF |
| Accuracy |
± (3% of full scale + 0.5 kV) |
| Voltage Waveform Distortion |
≤5% |
| Condition of Use |
Indoor, Outdoor |
| Humidity |
≤85%RH |
| Power Supply |
AC 50Hz, 220V ±5% |
| Temperature |
14 °F to 104 °F (-10 °C to 40 °C) |
| Weight |
Control: 13.23 lbs (6 kg); HV Tank I: 66.14 lbs (30 kg); HV Tank II: 110.23 lbs (50 kg) |
