| Specification |
Description |
| Processor |
Intel 6th–10th Gen Celeron or Core i3/i5/i7 |
| Operating System |
Windows 10 / Linux |
| Memory |
DDR4 2400 MHz, up to 16 GB |
| Storage |
1× mSATA, 1× SATA, 1× M.2 (NVMe) |
| Network Ports |
2× RJ45 Gigabit Ethernet (10/100/1000 Mbps) |
| Serial Ports |
2× RS232 (or 1× RS485) |
| Display Output |
1× HDMI |
| USB Ports |
6× total (4× USB 3.0, 2× USB 2.0) |
| Audio |
1× Combo Line-out/Mic-in (2-in-1) |
| Wireless Expansion |
1× Mini PCIe slot for Wi-Fi or 4G module |
| Chassis |
Aluminum alloy molded housing |
| Installation Method |
Embedded mounting |
| Dimensions (W×D×H) |
168 × 126 × 58 mm (6.61 × 4.96 × 2.28 in) |
| Weight |
1 kg (2.20 lb) |
| Operating Temperature |
-20°C to 60°C (-4°F to 140°F) |
| Storage Temperature |
-30°C to 70°C (-22°F to 158°F) |
| Humidity |
5%–95%, non-condensing |
| Power Input |
DC 12 V @ 5 A |
| Package Size |
228 × 186 × 118 mm (8.98 × 7.32 × 4.65 in) |
| Package Weight |
1.3–1.5 kg (2.87–3.31 lb) |
