| Emitter Type |
OTDR LD |
| Brand |
OEM |
| Connector Type |
OTDR FC, PC (or SC or ST) |
| Wavelength |
1310±20nm / 1550±20nm |
| Dynamic Range |
32/30 dB |
| VFL |
1 mW |
| Linearity |
±0.05 dB/dB |
| Measure Time |
OTDR 15s, 30s, 1min, 2min, 3min |
| Range |
74.5 mi to 99.5 mi (120 km to 160 km) |
| Event Dead Zone |
< 4.92 ft (<150 cm) |
| Attenuation Dead Zone |
< 26.2 ft (<800 cm) |
| Pulse Width |
5ns, 10ns, 30ns, 100ns, 300ns, 1.0us, 2.5us, 10us |
| Distance Uncertainty |
± (328.1 ft (1.0 m) ± 0.005% x testing distance ± resolution) |
| Loss Resolution |
0.001dB |
| Distance Resolution |
3.94 in (10 cm) |
| Data Storage |
OTDR 1000 traces |
| Display |
3.5 in TFT color LCD |
| Interface |
USB |
