Description
Features
- 6xCOM (two of them supports RS485 or 422)
- One-key restore, watchdog, diskless boot
- Low power fan-less
Technical Specifications
| CPU | Core i5-4278U |
| Memory | 1 x DDR3L SODIMM, Max 8GB |
| Storage | 1x MSATA 1x HDD or SSD |
| Display | 1 x HD-MI, 1x VGA |
| Network | 2 x GbE RJ45 i211 or i210 |
| I/O | 2x USB3.0, 6x USB2.0, 2 x LAN(GbE RJ45 i211 or i210), 6 x COM (2 of them supports RS485 or 422), 1x HD-MI, 1 x VGA, 1 x Power Button, 1 x 3.5mm Jack, 1 x Mic in, 2 x Antenna port, be used for WIFI or 3G or 4G |
| Expansion Slot | 1x Mini-PCIe half card, support WIFI Blue-tooth, 1 x Mini-PCIe full card (with SIM card holder), support 3G or 4G module, WIFI Blue-tooth |
| BIOS | AMI EFI BIOS |
| WDT | Support hardware reset (256 level, 0 to 255 sec) |
| Operation System | Windows 7 or 8 or 10， WES 7 or 10， LINUX |
| External Power Supply | AC 100 to 240V |
| Working Voltage | DC 12V |
| Power Consumption | ≤15W |
| Material | Aluminum Alloy |
| Colour | White |
| Relative Humidity | 10% – 95% RH, Non-Condensing |
| Operating Temperature | -4°F to 158°F (-20 to 70 °C) |
| Storage Temperature | -22°F to 158°F (-30°C to 70°C) |
| Dimensions (W x D x H) |
8.27 x 5.91 x 2.69 in (210 x 150 x 68.4 mm) |
| Net Weight | 3.31 lbs (1.5 kg) |
| Gross weight | 5.51 lbs (2.5 kg) |
