| Standard |
Compatible with IEEE 802.3, IEEE 802.1Q (VLAN) |
| Interface Rate |
10/100 Mbps, half/full duplex auto-negotiation |
| MAC Address Capability |
4096 |
| Connector (Ethernet) |
RJ45, supports Auto-MDIX |
| Interface Standard |
Complies with protocol G.703 |
| Code Rate |
2.048 Mbit/s ± 50ppm |
| Connector (E1) |
BNC (unbalanced) / RJ45 (balanced) |
| Jitter Tolerance |
Conforms to G.742 and G.823 |
| E1 Impedance |
75 Ω (unbalanced), 120 Ω (balanced) |
| Power Supply |
AC 180 V to 260 V; DC –48 V; DC +24 V |
| E1 Impedance |
75 Ω (unbalanced), 120 Ω (balanced) |
| Color |
Black |
| Working Humidity |
5 % to 95 % (no condensation) |
| Power Consumption |
≤ 10W |
| Working Temperature |
14 °F to 122 °F (-10 °C to 50 °C) |
| Weight |
2.87 lb. (1.3 kg) |
| Size |
8.50 in × 5.12 in × 1.22 in (21.6 cm × 13 cm × 3.1 cm) (W x D x H) |
