| Type |
OTDR |
| Application |
Telecommunication |
| Fiber Type |
SMF |
| Network |
Wireless LAN |
| Optical Connector |
FC/SC/ST (universal connector) |
| Wavelengths |
1310 nm /1550 nm ± 20 nm |
| VLS Center Wavelength |
650 nm ± 20 nm |
| VLS Output Power |
< 1 dBm |
| VLS Interface |
FC/UPC |
| Dynamic Range (HW-350TA) |
28 dB /26 dB |
| Dynamic Range (HW-350TB) |
32 dB /30 dB |
| Pulse Width |
10 ns, 30 ns, 50 ns, 100 ns, 300 ns, 1.0 µs, 2.5 µs, 10 µs |
| Event Dead Zone |
8.2 ft (2.5 m) |
| Attenuation Dead Zone |
45.9 ft (14 m) |
| Distance Range |
0.3 miles to 75 miles (0.5 km to 120 km) |
| Distance Measurement Accuracy |
± (3.3 ft + sample space + measurement distance x 0.005%) |
| Linearity |
±0.05 dB/dB |
| Memory Capacity |
1000 |
| Display |
3.5 in LCD |
| Battery |
NiMH Smart Charge Battery |
| Continuous Working Time |
> 10 hours (From Bell core TR-NWT-001138) |
| Dimension (From Image) |
9.1 in x 4.7 in x 2.4 in (23 cm x 12 cm x 6 cm) |
| Weight |
31.75 oz (0.9 kg) |
